Colorlight X20M LED Video Controller

Beschreibung

The Colorlight X20m is a powerful controller with 4K video input and processing capabilities.
X20m has a loading capacity of 13.10 million pixels, 20 Gigabit Ethernet ports, and 4×10G optical fiber ports (2 active and 2 standby).
It provides flexible screen control and high-quality image display through its practical functions.

Input
.Maximum 4096×2160@60Hz.
.4K input interface: 1× DP1.2, 1× HDMI2.0.
.2K input interface: 2× HDMI1.4, 2× DVI.
.U-DISK interface: 1× USB3.0.
Output
.Maximum loading capacity 13.10 million pixels.
.20 Gigabit Ethernet ports output or 4×10 Gigabit optical ports output. (2 active and 2 standby) .
Audio
.1× 3.5mm input.
.1× 3.5mm, support HDMI and DP audio outputs.
Function
.Up to 6-window display, 1 layer per window.
.Support freely moving the window, the size is at least 64×64.
.Support freely cropping and seamless switching, the size is at least 64×64.
.Adjusting display color gamut with precision color management, it needs corresponding specific receiving cards.
.lock internal sync, input signal source frame, automatic phase locking (according to the layer).
.Bright and color temperature adjustment with precision.
.3D display (purchase separately).
.Better grayscale at low brightness for improving the grayscale performance in low brightness.
.128 scene parameters can be saved and recalled.
.Upgrade program and play photos, videos with U-disk.
.OSD is used to play videos, pictures and adjust the screen display (optional ).
Control
.USB port for control and cascading.
.RS232 protocol.
.LAN port for TCP/IP control.
.Android APP for phones and tablets.

Size: W×H×L/482.6mm×103.0mm×415.0mm
Weight: 9KG
