Novastar H5 video wall splicer

Nova star
Vergleich

Novastar H5 video wall splicer is a flagship all-in-one video splicing processor,
designed specifically for fine-pitch LED applications. It is the first All-in-One splicer and controller in the industry, which greatly simplifies system integration.
With the leading image processing technology in the industry, H5 series can give you an astonishing visual effect, truly making it the perfect solution for fine-pitch LED applications.

$1,750.00

Artikelnummer: H5 Kategorie: Schlüsselworte: ,

Beschreibung

Specifications: H5 video wall splicer
Chassis:5U
Max, Loading Capacity (LED 4K Sending Card):39 million pixels
Max, Input Cards:10
Max, 4K Sending Cards:3
Irregular screen configuration:√
Max, Layers:A single card supports 16 layers
Max, Presets: 2000
10bit, HDR, 3D: √
Redundant Power Optional: √

(Need to add Input and Output card for Work! Please contact us for add.)

Allows for flexible configuratoin of input cards (Need to add, Not include)
H_4xDVI input cardl: DVI×4
H_4xHDMI input cardl: HDMI1.3×2+HDMI1.4×2
H_1xHDMI2.0+1xDP1.2 input cardl: HDMI2.0×1+DP1.2×1
H_1×HDMI2.0 input cardl: HDMI2.0×1
H_2×HDMI2.0 input card
(*H15 and H15 Enhanced)l: HDMI2.0×2
(*H15 and H15 Enhanced)
H_2xRJ45 IP input cardl: RJ45 Gigabit Ethernet ports ×2
H_4x3G SDI input cardl: 3G-SDI×4
H_1×12G-SDI input cardl: 12G-SDI×1, 12G-SDI LOOP×1
H_2xCVBS+2xVGA input cardl: CVBA×2+VGA×2
H_4xVGA input card VGA×4
H_2xDP1.1 input cardl: DP1.1×2

Allows for flexible configuration of output cards
H_16xRJ45+2xfiber sending cardl: RJ45 Gigabit Ethernet outputs ×16+OPT outputs×2
H_2xRJ45+1xHDMI1.3 preview cardl: RJ45 Gigabit Ethernet outputs ×2+HDMI1.3×1
H_20xRJ45 sending cardl: RJ45 Gigabit Ethernet outputs×20

Zusätzliche Information

Gewicht 25 kg
Größe 78 × 62 × 35 cm
