P4 Voller Farbe-SMD-LED-Modul

SMD LED module, SMD LED module
One Order over 500 USD Free of delivery;
Over 1500 USD 5% discount;
Over 3000 USD 10% discount.

Pixel pitch: 4mm
Module Size: 256X128 mm
Model Pixel: 64X32 Pixels
lattice density: 62500 dots/square meter

$13.50 $12.50

Artikelnummer: P4 Module Kategorie: ,


Module: P4 Full Color SMD LED Module
Pixel pitch 4mm
Module Size 256X128 mm
Model Pixel 64X32 Pixels
lattice density 62500 dots/square meter
Pixel form 1R1PG1GB SMD
Best viewing distance 2m~100m
Max power consumption 800W/square meter
Ave power consumption 400W/square meter
Max power per module 27W
warranty 1 year
Drive mode( Optional) Constant current 1/16 scan
Control system DVI card+Full color control card
Pixel type Real pixel
refresh frequency >=400HZ
Horizontal View Angel > 110 degree
Working Environment
Temp:-20Celsius degree-+60Celsius degree
Humidity : 10%-90%
Working voltage DC5V
Lifetime >=100000 hours
Gray scale 12 bit/ 1 color
Color display manual adjust
Brightness 1000 cd/square meter
Blind spot rate <0.00001
Waterproof Class IP43
Software Support window series system

You'd better buy all modules at a time for one led screen, in this way, we can make sure that all of them are of the same batch.
For different batch of LED modules have a few differences in RGB rank, color, frame, brightness etc.
So our modules can't work together with your previous or later modules.
If you have some other special requirements, please contact our online sales.

Zusätzliche Information

Gewicht 0.4 kg
