Meanwell NDR-120-12 Industrial Rail Power

One Order over 500 USD Free of delivery;
Over 1500 USD 5% discount;
Over 3000 USD 10% discount.

NDR-120 is one economical slim 1 20W DIN rail power supply series, adapt to be installed on TS-35/7.5 or TS-35/1 5 mounting rails. The body is designed 40mm in width, which allows space saving inside the cabinets.



.Universal AC input 1 Full range
.Protections: Short circuit / Overload / Over voltage / Over temperature
.Cooling by free air convection
.Can be installed on DIN rail TS-35/7.5 or 15
. UL 508 (industrial control equipment) approved
.BS EN/EN61000-6-2(BS EN/EN50082-2) industrial immunity level
.100% full load burn-in test
.3 years warranty

Power: 12V 10A 120W
Voltage Tolerance: ±2%
Setup, Rise Time: 1200ms/230VAC 2500MS,60ms/115VAC at Full load

Voltage Range: 90-264VAC / 127-370VDC
Frequency: 47-63HZ
Efficiency: 85.5%

Over load: 105-130% rated output power
Over Voltage: 14-17V
Working Temp: -20 to +70 degree
Working Humidity: 20-95% RH non-condensing

Authentication: UL TUV CB EAC EMC CE UK
Size: 40*125.2*113.5mm
Weight: 0.6KG

More Detail: Meanwell NDR-120-12

Información adicional

Peso 0.6 kg
Dimensiones 12.5 × 12 × 4 cm
