P3.91 LED dance floor module

Description

1. Core Features
Pixel Pitch: 3.91mm
Brightness: ≥1200 cd/m²
Viewing Angle: 120° (H/V)
Refresh Rate: ≥3840Hz
Resolution: 64×64 pixels per module (250×250×18mm)

2. LED Specifications
LED Type: SMD1921 (1R1G1B)
Color Depth: 8192 grayscale
Lifespan: >100,000 hours
Drive Method: Constant current, 1/32 scan

3. Durability & Protection
IP Rating: Waterproof (washable)
Load Capacity: ≤2 tons
Surface: Anti-slip PC composite (UV-resistant, non-yellowing)
Operating Temp.: -20°C to +55°C
Protections: Anti-static, dustproof, over-current/short-circuit/over-voltage

4. Power & Control
Power Input: 5V ±10%
Power Consumption: 280W/m² (avg), 400W/m² (max)
Power Consumption per module: 25W (max)
Control System:
Supports Windows OS
Inputs: VGA/DVI/S-Video/PAL/NTSC
Transmission: Fiber optic (30km) / Ethernet (100m)

5. Applications
Stages, exhibitions, retail, sports venues, interactive floors (touch-sensitive optional).
